Doppler Flow Velocity and Flow Rate Meter

The Doppler Flow Velocity and Flow Rate Meter is a flow measurement instrument designed for rivers, open channels, and pipelines. Utilizing ultrasonic detection technology, it offers high measurement accuracy, excellent stability, and minimal susceptibility to environmental factors. With no moving parts, low maintenance requirements, and high operational reliability, it is the premier choice for portable flow velocity and flow rate measurement.

Principle: In acoustics, when relative motion occurs between a sound source and receiver (i.e., probe and reflector), the frequency of the echo changes. This frequency shift is known as the Doppler effect. Sound wave frequencies increase when moving toward the observer and decrease when moving away. The Doppler flow meter calculates flow velocity by measuring this frequency change.

Applications of Doppler Flow Velocity and Flow Rate Meters include sponge cities, river chief system management, inland river monitoring, natural rivers, open channels, pipelines, aquaculture, and similar scenarios.

• Measures flow rate, velocity, and water level in pipes, channels, and natural rivers.

• A single velocity sensor, easy to install, is suitable for flow measurement in municipal sewage pipes, channels, partially filled pipes, various channels, irregular river courses, natural streams, and discharge outlets. It can be concealed and operates stably over the long term.

• Provides both instantaneous and cumulative flow values.

• Features a 2.8-inch color display with text and graphics for easy operation and flow analysis.

• Stores up to 10,000 data points, exportable via included USB drive.

• Low sensor power consumption: <0.8W during flow velocity measurement.

• Chinese/English interface with one-touch switching.

• Built-in rechargeable lithium battery for over 8 hours of operation.

• Integrated pressure-type water level sensor and temperature sensor.
