Disinfectant tester

Disinfectant tester

  • Product Number:LD-YXL
  • Product Difference:Used for effective chlorine concentration testing in food factories, hospitals, sewage treatment, etc., and for determining the effective chlorine content in bleaching powder, bleaching powder tablets, and similar disinfectants

Product Introduction

The disinfectant tester employs spectrophotometry and is designed and manufactured in accordance with the reference standard GB/T 5750.11-2023, replacing the traditional visual colorimetry method. This eliminates human error, resulting in higher detection resolution, direct readings, greater user-friendliness, and simpler operation.

The disinfectant tester can be widely applied in food factories, hospitals, wastewater treatment, breeding centers, aquaculture, and disinfection of septic tanks for measuring effective chlorine concentration. It is also suitable for determining the effective chlorine content in bleaching powder, bleaching powder tablets, and similar disinfectants, ensuring the preparation of qualified disinfectant water that meets national disinfection standards.

Product Features

  • Android smart system for more convenient and efficient operation.

  • Faster detection speed with on-site data reading.

  • Configured with a cloud monitoring platform, detection results can be directly transmitted wirelessly to the platform for long-term and short-term water quality analysis and management support.

  • AC/DC compatible, with built-in rechargeable lithium battery, environmentally friendly and durable, supporting continuous indoor and outdoor operation.

  • Built-in operating procedures, simple to use, no training required, ready to use immediately.

  • Portable, compact size, lightweight, convenient for outdoor testing.

  • Compact and aesthetically pleasing design, stable operation with no maintenance required, offering excellent cost-effectiveness.

  • Features an imported cold light source with stable optical performance and a lifespan of up to 100,000 hours.

Product parameters

Test ItemFree Chlorine Concentration, Free Chlorine Content
Reference StandardGB/T 5750.11-2023
Measurement Range0.5~300 mg/L (segmented); 0.1~60% (segmented)
Measurement MethodPhotometric Colorimetry
Measurement Error≤10%
Repeatability<0.5%
Stability<0.5%
Wavelength selectionAutomatic
Operating systemAndroid smart operating system
Display screen3.5-inch color LCD touchscreen
Sensitivity (Absorbance)0.001
Operating Environment0~50°C, 0~90% relative humidity
Data StorageOver 80,000 entries
CommunicationType-C, Wi-Fi, Bluetooth
Battery5600mAh lithium-ion battery
Continuous operating time8 hours
Supply voltage5V DC
Dimensions and weight190×77×72 mm, 325g
Supported languagesSimplified Chinese or English
