Veterinary drug residue detector

Veterinary drug residue detector

  • Product Number:LD-SY02
  • Product Difference:6-channel synchronous detection, completing multiple sample readings in ≤5 seconds, suitable for high-throughput applications

Product Introduction

The Veterinary Drug Residue Rapid Detection Instrument is a highly efficient, high-throughput optical detection device specifically designed for multi-channel gold-labeled test strips (such as colloidal gold immunochromatographic test strips). The instrument employs multi-channel synchronous detection technology, enabling simultaneous reading of multiple samples, significantly enhancing detection efficiency, and is suitable for bulk screening and high-throughput detection requirements. It is widely applied in medical diagnosis, food safety, scientific research experiments, and other fields.

The instrument's detection parameters include:
1. Lean meat hormones: Clenbuterol hydrochloride, Salbutamol, Ractopamine, Estradiol, Quinethazone, etc.
2. Antibiotic residues: Tetracyclines, Nitrofurans, Sulfonamides, Beta-agonists, Fluoroquinolones, Sulfonamides, Quinolones, Sulfadiazine, Florfenicol, Amantadine, Tilmicosin, Gentamicin, Lincomycin, Streptomycin, Enrofloxacin, Ciprofloxacin, Cefadroxil, Penicillin, Amoxicillin, etc.
3. Aquatic Product Safety: Malachite green, chloramphenicol, furazolidone, furazolidone, furazolidone, furazolidone, etc.
4. Drug residues in eggs: Chloramphenicol, tetracycline, sulfonamides, quinolones, furazolidone, furazolidone, furazolidone, furazolidone, florfenicol, amoxicillin, cefalexin, erythromycin, streptomycin, etc.
5. Animal diseases: Avian influenza, Newcastle disease, foot-and-mouth disease in cattle and sheep, tuberculosis in cattle and sheep, cysticercosis in cattle and sheep, brucellosis in cattle and sheep, small ruminant diseases, porcine reproductive and respiratory syndrome virus, classical swine fever virus, pseudorabies virus in pigs, porcine parvovirus, porcine circovirus, canine parvovirus, canine distemper virus, canine rabies virus, etc.

Product Features

  • Multi-channel synchronous detection: Supports 6 channels, enabling simultaneous detection of multiple samples to improve efficiency.

  • High-precision optical system: Utilizes multi-wavelength LED light sources (650nm) and high-sensitivity photodetectors to minimize errors.

  • Intelligent operation: Touchscreen control with built-in quality control functions; supports QR code scanning for sample information entry to prevent human errors.

  • Data management: Large-capacity storage (≥10,000 data sets), supports USB/Wi-Fi export; can connect to cloud databases.

  • Rapid testing: Completes reading of multiple samples in ≤5 seconds, suitable for high-throughput applications.

  • Portable and durable: Available in desktop or portable designs, with some models supporting battery power; dustproof and splash-resistant design, suitable for laboratory or field environments.

Product parameters

Device Parameters

7-inch capacitive touchscreen, resolution 1920 x 1200, internal storage 1+8GB, Operating System Android 7.1
Detection MethodReflective Photoelectric Detection
AccuracyError Value ≤ 5%
StabilitySW (Coefficient of Variation) ≤ 5%
RepeatabilityCV (coefficient of variation) ≤ 3%
Resolution0.001
Detection channels6-channel detection
Detection time< 5 seconds (single card and multi-card), capable of performing colloidal gold qualitative/ semi-quantitative testing of samples
Test resultsTest items, concentration of the tested substance, testing unit, inspected unit, tester, testing time, detection limit, and other information can be displayed on the touch screen and printed via the built-in printer of the instrument

Data transmission

WiFi, Bluetooth, USB, RF card reading, external barcode scanning module
Data processingData aggregation and upload to regulatory platforms can be performed via communication ports
Project expansionSupports project expansion functionality
Temperature rangeThe testing channel integrates incubation and testing, temperature range: room temperature +5°C to 60°C
PrinterThermal printer (thermal paper: 57×20 mm)
Interfaces2 USB ports; 1 USB-B port; 1 LAN port; DC power interface 5.5/2.1mm
Power supplyInput AC 100V-240V/1.3A 50Hz, output DC 12V/5A
Dimensions and weight308mm x 205mm x 91mm, approximately 2.7kg
