Rotary Cutting Machine

Rotary Cutting Machine

  • Product Number:LD-2205
  • Product Difference:Slice thickness range: 0μm–60μm The sample clamping system can be adjusted in any direction within three-dimensional space

Product Introduction

Rotary Microtome Manufacturer [LANENDE Technology] With years of experience in developing and manufacturing rotary microtomes, our instruments feature simple operation and accurate testing data. As the manufacturer, we offer competitive pricing. Call us today for inquiries!

Product Features

  • The streamlined housing maintains a clean, professional appearance. The top surface accommodates blades and wax blocks, allowing easy access and replacement within the field of view.

  • The new cross-roller guide and micro-advance mechanism feature permanent lubrication, eliminating the need for oiling and frequent maintenance. The chip tray facilitates easier instrument cleaning.

  • The rapid block trimming function significantly boosts work efficiency.

  • The sample clamping system adjusts freely in all three dimensions for user-friendly operation.

  • Dedicated disposable blade holders ensure optimal sectioning results with every blade. The left-right blade holder movement allows safe and convenient blade handling.

  • The entire machine incorporates ergonomic design principles, providing a comfortable experience for operators.

  • The dual-purpose blade holder allows easy switching between wide and narrow blades.

Product parameters

Slice Thickness

0 μm ~ 60μm
Setting Range

①0 μm ~ 2 μm Increment value 0.5 μm; ②2 μm ~ 10μm Increment value 1μm; ③10 μm to 20 μm: Increments of 2 μm; ④20 μm to 60 μm: Increments of 5 μm

Specimen Travel RangeSpecimen vertical travel: 50 mm, Horizontal specimen travel: 20 mm
Maximum section size55 × 45 mm
Sectioning accuracy±5%
Specimen adjustment rangeHorizontal: 8°, Vertical: 8°, Rotation 360°
Carriage Base Travel RangeForward/Backward ±25mm, Left/Right ±25mm
Carriage Angle0~15°
Overall Dimensions500*480*280mm
