COD Digester

COD Digester

  • Product Number:LD-X06
  • Product Difference:6-hole design enables one-touch digestion for multiple testing parameters such as COD, total phosphorus, total nitrogen, and other items

Product Introduction

The Portable Smart COD Digester is a new multi-functional rapid digestion instrument developed in accordance with the environmental protection industry standard HJ/T399-2007. Featuring a 3.5-inch capacitive touchscreen for intelligent and safe operation, it offers rapid heating with uniform and stable temperature control. It enables one-touch digestion for multiple testing parameters such as COD, total phosphorus, total nitrogen, and more.

The COD Digester is widely applicable for water quality testing across diverse sectors including research institutes, wastewater engineering, water environment monitoring, petrochemicals, metallurgy and steel, biopharmaceuticals, food and dairy, wool spinning and dyeing, electronics and machinery, aquaculture, photovoltaics, leather, and papermaking.

Product Features

  • 3.5-inch color LCD touchscreen display with clear and intuitive content.

  • Pre-programmed with 4 digestion protocols for one-touch operation—no modifications required.

  • Features a transparent, ventilated splash guard for safe, visible monitoring of digestion progress.

  • Includes constant-temperature heating, over-temperature protection, automatic timing, and audible alerts.

  • Timing automatically initiates upon reaching the preset digestion temperature.

  • Digestion time and temperature are fully customizable.

Product parameters

Digestion Capacity6 tubes
Heating SpeedReaches 165°C within 10 minutes
Digestion Volume0-10 ml
Temperature Control ModeIntelligent PID Temperature Control
Temperature Control Accuracy±0.5℃
Digestion Temperature RangeRoom Temperature - 200℃
Time Setting0-200min
Digestion ApertureΦ16mm/10ml Digestion Colorimetric Tube
Tube Depth55mm
Display3.5-inch Color Capacitive Touchscreen
Power Consumption400W
Special FeaturesOne-Touch Digestion, Over-Temperature Protection, Audible Alarms, Custom Settings, Countdown Timer
Dimensions & Weight245 × 163 × 192 mm (L × W × H), <2.5kg
Device LanguageChinese/English
Ambient Temperature5~40℃
Relative Humidity≤85% (non-condensing)
Power SupplyAC(220±22)V, (50±0.5)Hz
