Smart Microwave Digestion System

Smart Microwave Digestion System

  • Product Number:LD-WB6
  • Product Difference:High-pressure digestion vessels process ≥6 samples per batch, accelerating sample digestion reactions under high-pressure conditions

Product Introduction

The intelligent microwave digestion system provides a rapid, safe, and automated solution for accelerating sample digestion reactions under high-pressure conditions. It is widely used in food science, environmental protection, disease control, quality supervision, commodity inspection, research institutes, and other fields.

Product Features

  • Features continuous automatic frequency conversion control without microwave pulses, extending instrument lifespan and ensuring uniform electromagnetic wave distribution.

  • 360° continuous rotation in the same direction guarantees uniform microwave distribution, ensuring identical microwave environments for all samples and enhancing experimental consistency.

  • The 52L large-capacity chamber is constructed from 316L stainless steel. Its self-locking, buffer-equipped explosion-proof door ensures operator safety and structural integrity during abnormal reactions. The door-chamber seal meets national standards for microwave containment.

  • The safety explosion-proof membrane provides dual protection. When pressure inside the vessel exceeds the membrane's tolerance, it ruptures first to vent gases, preventing vessel damage and personal injury.

  • A dual temperature-pressure control system regulates digestion parameters with real-time display.

  • Microwave heating automatically stops when the pressure inside the vessel exceeds the preset safety threshold.

Product parameters

Host ParametersPower Requirements220-240 VAC 50/60Hz 8A
microwave frequency2450MHz
Microwave Output Power0~1600W
Total installed power2600W
Microwave Output CharacteristicsMicrowave non-pulsed continuous automatic frequency conversion control, 0–100% automatic output
Microwave UniformityVertical dual-wave guide design, three-dimensional output technology, and matched harmonic power frequency achieve high field uniformity
Microwave Cavity52L capacity, 316-grade stainless steel cavity with 6 layers of corrosion-resistant, high-temperature Teflon coating
Exhaust and Cooling System

① The furnace chamber is equipped with a high-power exhaust system, enabling various reactions to be conducted continuously for extended periods in a well-ventilated, safe, and easily observable environment

② The furnace chamber ventilation utilizes acid-resistant centrifugal fans with high airflow capacity, delivering an exhaust rate of no less than 5m³/min

③ The furnace chamber incorporates air-cooling functionality, continuously lowering the temperature of the reaction vessel with real-time display of temperature and pressure

Turntable Design360° unidirectional continuous rotation ensures uniform microwave distribution, guaranteeing identical microwave environments for all samples and enhancing experimental consistency
Control MethodTouchscreen interface with 8-inch TFT-LED (800x480 color) display. Enables remote direct reading of reaction progress, real-time monitoring of sealed reactor temperature and pressure, and live visualization of temperature-pressure curves
Operating LanguageSimplified Chinese
Automatic Protection FunctionEquipped with a fault self-diagnostic system. When either the temperature control or pressure control system malfunctions, the instrument automatically cuts off microwave emission and triggers an alarm.
Control System ParametersTemperature Control SystemEmploys contact-type temperature control for precise, error-free regulation using high-precision platinum resistance temperature sensors; continuously monitors, controls, and displays real-time temperature readings and curves within the microwave digestion reactor vessel
Temperature control range0~300℃
Temperature control accuracy±0.5℃
Temperature Control CapabilityRapid Heating Function
Pressure Control SystemEmploys non-contact pressure control for precise, error-free regulation—a century-proven technology. Continuously monitors, controls, and displays pressure readings and curves within the microwave digestion vessel in real time.
Pressure Control Range0~6MPa, 0-10MPa, 0-15MPa, selectable
Pressure Control Accuracy0.01MPa
Pressure ProtectionAutomatically adjusts/stops microwave transmission upon overpressure and triggers an alarm
Reaction Vessel ParametersHigh temperature≥300℃
High pressure≥1500psi
Inner Tank MaterialPTFE Material
Explosion-proof Outer Jacket MaterialPEEK Aerospace Material
Inner Tank Reaction Volume100ml
※High-pressure digestion vessel batch capacity≥6 samples/batch (upgradable to 40 positions without rotor replacement)
Explosion-proof diaphragmUtilizes ceramic clamping. Ceramic remains stable under heat, whereas PTFE deforms when heated and fails to function as an explosion-proof membrane. Ceramic components are employed for clamping.
Digestion Vessel Operation Mode360° uniform continuous rotation ensures even microwave distribution. Each sample experiences identical microwave exposure, enhancing experimental result consistency.
