Fully automatic pesticide residue detector

Fully automatic pesticide residue detector

  • Product Number:LD-QN20
  • Product Difference:20 channels, automatically add reagents according to reagent requirements, on time and in the correct quantity

Product Introduction

The fully automatic pesticide residue detector is designed and manufactured in accordance with national standards (GB/T 5009.199-2003) and agricultural standard methods (NY/T 448-2001), utilizing the enzyme inhibition rate method. It can accurately and rapidly detect the residual levels of organophosphorus and carbamate pesticides in solid or liquid samples such as vegetables, fruits, agricultural products, and tea. It is widely applicable to various levels of food safety monitoring departments, vegetable production bases, vegetable wholesale bases, farmers' markets, food supermarkets, mobile food safety testing vehicles, health and epidemic prevention, environmental protection, and other fields.

Product Features

  • User-friendly interface for easy operation.

  • Equipped with an automatic temperature control system.

  • Automatically adds reagents according to requirements, on time, and in the correct quantities, improving work efficiency.

  • The instrument automatically checks and alerts for improperly placed or abnormal samples.

  • Utilizes advanced cold light sources to ensure stable light output and accurate data.

  • Includes a built-in miniature thermal printer for quick printing of test results, facilitating data retention.

  • Large-capacity storage can store up to 120,000 data points, meeting customer requirements.

  • The instrument can be connected to a computer via a data cable to upload test data to the computer.

  • The instrument automatically cleans the tubing to prevent reagent contamination.

  • The instrument's reagent consumption is consistent with that of conventional instruments.

Product parameters

Wavelength configuration410
Reagent positions3
Reagent needles6 (3 spare)
Detection channels20
Reaction Temperature37°C
Touchscreen7-inch touchscreen
CuvetteCapacity 0–4.5 ml
Reagent KitMatching reagent storage box, removable as a whole
Cleaning functionAutomatic cleaning of reagent tubing, preventing reagent contamination
Real-time monitoringDisplays operational status during instrument testing
Printing functionBuilt-in thermal printer
Data storageLarge-capacity storage, capable of storing 120,000 data points
Data interfaceExternal USB interface, network cable interface
Dimensions and weight410mm x 290mm x 202mm, approximately 6 kg
